80x80mm Scan Field 9.4um Telecentric Scan Lens for CO2 laser PCB processing

Telecentric scanning lenses are special configurations in which the arrangement of optics is designed to focus down the beam so that it is always perpendicular to the flat field. This is accomplished by ensuring that the system ‘stop’ is located at the front focal point of the lens system. The stop’ is located at the position where the beam is deflected from the axis. In a single-axis scanning system, this location is at the scanning mirror. For two-axis scanning, the stop is midway between the mirrors. Adaptors for major scan head providers are available upon request.

Model：TSL-9.4-80-150-D25
Design Wavelength：9.4μm (CO₂ Laser)
EFL (Effective Focal Length)：150mm
FFL (Flange Focal Length)：225.1mm
Scan Length：115mm
Scan Field：80×80mm
Max Input Beam Diameter：25mm
M1-M2 Distance：30.9mm
Total Lens Length：113mm
WD (Working Distance)：144.4mm
Diagonal Scan Angle：±21.7deg
Optical Transmittance：>97% @9.4μm
Type：Telecentric F-theta Scan Lens
