20X Achromatic Microscope Objective Lens with Anti-Reflective Coating OEM Support

Our NUV Plan Apo 20x is a high-performance, infinity-corrected industrial objective engineered for superior imaging from the Ultraviolet (UV) to the visible spectrum. Featuring advanced apochromatic (APO) optical design and specialized UV-enhanced anti-reflection coatings, it delivers exceptional resolution, contrast, and transmission from 355nm to 700nm. With a large Ø40mm image circle and a generous 20mm working distance, it is the ideal solution for the most demanding high-resolution inspection applications that leverage UV light.

Key Specifications:

• Magnification: 20X
• Numerical Aperture (NA): 0.45
• Working Distance (WD): 20 mm
• Optical Design: M Plan Apochromat (infinity corrected)
• Focal length: 10 mm
