SL-355-220-330Q-D12 355nm UV F-theta Scan Lens | 220×220mm 330mm EFL

The SL-355-220-330Q-D12 is a high-precision 355nm UV F-theta scan lens, specially optimized for 355nm nanosecond ultraviolet laser galvanometer scanning systems.

Operating Wavelength：355nm (UV Ultraviolet)
Effective Focal Length (EFL)：330 mm
Scan Field：220 × 220 mm
Max Input Beam Diameter：12 mm
Compatible Laser：355nm nanosecond UV laser
Matching Equipment：UV laser engraving machine, galvanometer scanning system
Interchangeable：opex uv ftheta equivalent lens

Send email to us

Product Detail

Product Tags

UV laser precision marking, PCB/FPC micromachining, glass & ceramic engraving, plastic surface etching, semiconductor wafer scribing, medical component fine processing.
